Features:
  • Products automatically feeding, testing, classification, loaded with features ..
  • Can be used with various types of instruments to carry out the assessment and classification packaging.
  • The application of products according to customers to specify the size.
  • Password input function, to prevent non-related personnel changes in program content.
  • Packaged with sealing temperature, position adjustable.
  • Automated packaging process before the blank, after the number of conduction band can be set.
  • The lack of material with seized packaging with knowledge, the prevention of air packages.
  • The overall operation of the speed of product can change the situation.

    Specifications:
  • Test Station 2 Station, (RDC / Z OR RDC / L)
  • Testing instrument Z, L: HP4287 RDC: HP4338B
  • Test fixture 4 endpoint independent contact
  • Classification Good, bad Commodities / Good into the packaging with
  • Way closure with heating tape
  • Operating speed of about 100PCS/Min
  • Voltage power AC220V1φ, 1.5KVA
  • Pressure demand 5-7Kg/cm ^
  • Overall dimensions of about 1300 (W) X1000 (D) X1800 (H) mm
  • Machine weighing about 360kg
DD motors mining operation the implementation of high-resolution
Human-computer screen control, easy to operate
XYθ axis
Adjustable measuring the location of the Block, testing the stability
End yield measured automatically into Tape
