Mechanical control system：
|
PLC (Programmable Logic Controller) FPG-C32T FP0-E16T |
|
Interface：
|
Touch screen (man-machine interface) (Color 640 * 480 points analytic geometry) | |
|
Test：
|
Sliding test first, test specifications are adjustable | |
|
Testing equipment：
|
Can be used with 4286A, 4287A, 4338B and other equipment | |
|
Test frequency range：
|
1-100 MHz | |
|
Test Type：
|
L / Q, Z, RDC | |
|
Maximum capacity：
|
40000pcs / Hr (Maximum) | |
|
Category chip type：
|
100505~453215 | |
|
Category number：
|
8 Bins | |
|
Shows the number of chips ：
|
Real-time display | |
|
Abnormal display：
|
Significant failure of the stable supply of electricity and rule out the possibility that description | |
|
Work area：
|
L:1040mm W:600mm H:1300mm | |
|
Voltage requirements： |
1φ2W 220V 60/50 Hz, 15AMP of the stable supply of electricity | |
|
Power consumption：
|
1 kw | |
|
Compressed air：
|
4~6 kg/cm Air Source | |
|
Line Drive：
|
2.0mm square for more than 3 core cable | |
|
Pressure source diameter：
|
8X6mm |
 |
